Why do machines fail? It's a fundamental question that has fascinated Guillermo Morales throughout a career that has taken him halfway around the world, to the highest levels of technical research and down into the minutiae of microscopic imperfections.
A Mexican/French national, now based at SKF's Research and Technology Development Centre in the Netherlands, Morales divides his time between overseeing industrial R&D projects and holding senior academic positions at the University of Lyon (INSA) and Imperial College London. He has made numerous contributions to the science of rotating machinery. One of the most significant has been his work on new ways to predict the operating life of rolling bearings under real-world conditions.
"You can design many mechanical components by just calculating stresses and making sure you do not exceed the fatigue limit. In this way you do not have to worry about fatigue, it will not happen” Morales says. "In bearings, the duty cycles are so long and the stresses are so high that you almost always get fatigue. You need a mathematical formulation to understand these stresses and their effect on component life.”
Early models integrating these factors appeared in the mid-20th century, with SKF scientists leading the charge. "Those early models introduced basic concepts that are still relevant today," says Morales, "like the difference between static and dynamic bearing capacity."
Prediction at the limit
Advances over the following 50 years improved model sophistication. By the 1980s, engineers could account for the fatigue limit — a stress threshold below which fatigue in the material barely accumulates. Morales notes that "20th-century models focused mainly on subsurface fatigue." However, advancements in manufacturing, such as clean steels, have largely resolved subsurface fatigue issues. Today, most bearing failures are triggered by a problem on the surface, such as poor lubrication, contamination, frictional heat, or electrical damage.
And the surface was something Guillermo Morales knew a lot about. After earning bachelor's and master's degrees in mechanical engineering in his native Mexico, he travelled to the University of Cambridge, UK, to pursue a Ph.D. in tribology: the science of friction, lubrication, and wear.
"My Ph.D. work was trying to model the effect and behaviour of roughness in lubricated contacts," he says. "In tribology, 'roughness' is a general way of describing any microgeometric feature. It can be a scratch, an indentation, or a texture on the surface." Such surface patterns are a headache for tribologists because they disrupt the thin films of lubricant that allow mechanical components to move smoothly over long periods of time.
But roughness is difficult to model: "People used to do numerical work to model roughness," recalls Morales, "but it's a very hard, time-consuming problem for a computer. You need a system of five equations with five unknowns distributed in time and space."
The key to Morales' dissertation was to find a simpler, faster way to tackle the complex mathematics of roughness. He did so by breaking it down into sinusoidal "waves". This dramatically simplified the calculations required, while still allowing any type of surface imperfection to be modelled as a collection of different waves.
The new approach reduced the computing power required to analyse complex surfaces by several orders of magnitude compared to older methods. His time at Cambridge also gave Morales a lifelong fascination with tribology.
After a few years in academic and industrial consulting roles, this fascination led Morales to SKF. He joined the company's research laboratory in January 2000 and soon found new applications for his modelling approach. One was simulating bearing performance in mixed lubrication environments, where contamination or lack of lubricant creates areas of direct metal-to-metal contact within a bearing. Another was a new modelling approach to evaluate the effect on life of the small indentations that can occur if a bearing is mishandled during manufacturing, shipping, or assembly.
Life in general
Fast forward a few years, Morales and his colleagues were successfully applying mixed lubrication and surface damage models to a wide range of problems within SKF and for its customers. In 2012, a new technical director approached Morales with a bigger challenge. "He said our bearing life models were useful, but they were too rigid," recalls Morales. "It takes too much effort to adapt the model to a different problem or to integrate new knowledge."
The technical director's request was simple, but daunting. Could Morales and his team take what they had learned about the effect of surface conditions on bearing life and build a general-purpose model that would better predict bearing life in the real world?
Their answer to this challenge was two years in the making. "We already had some of the key ingredients," says Morales. "To build a general-purpose bearing life prediction model, you have to simulate the operation of different bearings, under different conditions, over millions of cycles." Other parts of the model required the team to break new ground. In particular, Morales says, they had to develop an approach that combined their new surface damage models with traditional methods for estimating subsurface fatigue.
One model, many solutions
The first iteration of the SKF Generalized Bearing Life Model (GBLM) for conventional steel bearings was introduced as a concept to customers at the 2015 Hannover Messe. It offered the promise of an immediate solution to many challenges faced by design engineers every day.
"With a better life prediction model, you can design better machines," says Morales. "Our model helps designers select the optimal size and type of bearing for their application and allows companies to provide more reliable advice on maintenance and replacement intervals." The result is more efficient use of resources, with fewer breakdowns and less premature replacement of parts that still have life left in them.
Over the past decade, Morales and his colleagues have expanded the GBLM to include new types of bearings, notably adding models for the hybrid bearings now used in demanding applications ranging from turbomachinery to electric vehicle transmissions. They have updated the approach to reflect ongoing improvements in conventional bearing technology, including new steels, and better heat treatment techniques. The GBLM is also helping users make informed decisions about bearing remanufacturing intervals, based on the likely rate at which surface damage will accumulate in their applications.
Is there more to come? As principal scientist, Guillermo Morales now has much more on his plate than bearing life models, but he maintains a strong interest in the development of the GBLM.
"We have developed a flexible and extensible way to model different bearings, operating conditions and failure modes," he says, "but all such models need to be validated with data from experiments and tests. Advanced sensors are now giving us better insight into the conditions inside our bearings, and these insights will help us extend and improve our modelling approach.”
Guillermo Morales-Espejel, principal scientist at SKF.
