Maplesoft has announced a major new release of MapleSim, an advanced system-level modelling and simulation platform used by engineers to reduce development time and gain insight into system behaviour.
MapleSim enables engineers to take advantage of modern techniques in modelling and simulation, dramatically reducing model development time and risk while improving designs. The latest release provides tools that increase engineering design productivity during model development, as well as significant additions to toolchain connectivity that offer even greater cross-tool compatibility and opportunities for co-simulation.
To support engineering design productivity, MapleSim 2016.2 provides live simulations that let engineers see results as the simulation is running so they can track progress and investigate unexpected results immediately. Other improvements include a new 3D overlay for comparing simulation visualisations, which makes it easy to see changes in the behaviour of the model under different conditions, and tools for revision control that facilitate large projects involving multiple engineers working on the same model.
The new release also includes significant enhancements to toolchain connectivity. In addition to exporting models to the internationally recognised FMI standard, MapleSim now also supports direct import of models created in other FMI-compatible software, for both model exchange and co-simulation. Models exported by FMI-compatible modelling tools, such as LMS Imagine.Lab Amesim or Dymola, can be easily imported into MapleSim and used like any other model or subsystem. In this way, engineers can immediately leverage models developed using other software while taking advantage of the advanced modelling and analysis tools of MapleSim when developing their system-level designs. For dynamic models involving multiple simulation tools, MapleSim now allows engineers to seamlessly connect models that run in other tools into their MapleSim system-level simulations.
Enhancements to the MapleSim family of products also include expanded analysis tools for the MapleSim Battery Library and improved import facilities for the MapleSim CAD Toolbox. In addition, the MapleSim Connector for connectivity with Simulink, and the MapleSim Connector for FMI for exporting MapleSim models to other FMI-compatible tools, have been expanded to allow engineers to explore simulation results involving exported MapleSim models from within MapleSim, even though the simulation was done in the target tool.
MapleSim is available in English, Japanese, and French.
