researchers have designed and fabricated tiny new piezoelectric microactuators, the largest only a hair's breadth wide, based on coupling commercially available materials with existing micromachining technology.
The new actuators promise to be low cost, and capable of providing controlled force, high resolution and large displacements appropriate for applications in RF switches for cell phones, for example, or optical switches for wide screen TVs. Other potential applications include microfluidic pumps and valves, micromanipulators for nanoscale handling and atomic force microscope drives.
Dr. Srinivas A. Tadigadapa, associate professor of electrical engineering and a developer of the bonding process and microactuator, said, "These new piezoelectric microactuators are the first realised using microfabrication methods, a mature technology used to make computer chips and micromachines from silicon-based materials.
“Our new low temperature wafer bonding techniques, which make the actuators possible, can also be used for precision integration of dissimilar materials in other micro-electro-mechanical systems."
The new actuators and bonding process are described in a paper, Fabrication and performance of a flextensional microactuator, which appears in the current online edition of the Journal of Micromechanics and Microengineering (JMM).
The new actuators are made from flat strips of bulk PZT, a commercially available piezoelectric material that shrinks slightly when a voltage is applied to it, and a precision micromachined silicon beam. Bonding the silicon beam to the PZT amplifies and converts the PZT shape change into a convex deflection when the silicon beam buckles as the PZT shrinks.
In operation in the actuator, the measured deflection of the silicon beam shows a gain factor of 20 with respect to the PZT dimensional change.
For the bonding process in fabricating the new actuators, the
Dr. Tadigadapa noted, "The PZT depoles if you heat it too high. Therefore, the temperature is crucial. A low temperature solder bonding process at 200 degrees C was used in this work."
Using their new approach, the researchers have fabricated actuators with dimensions ranging from 350 to 600 microns in length, 50 to 100 microns in width, and five to six microns in thickness.
In tests, the actuators showed good repeatability with a large amplitude stroke of about eight microns when actuated using -100V to 100V. The bandwidth of the actuator was measured at 265KHz.
