Imaging the brain

Researchers at Stanford University have demonstrated a promising, minimally invasive optical technique that can capture micron-scale images from deep in the brains of live subjects.

The method, called two-photon microendoscopy, combines a pair of powerful optical and mechanical techniques into one device that fits in the palm of the hand.

Researchers want to image individual cells inside living subjects because it will give them insight into how cellular behaviour gives rise to the properties of organisms as a whole. For instance, the nerve cells of the hippocampus region of the brain give rise to important mental processes such as learning and memory.

Imaging living cells below the surface has been difficult to accomplish using conventional techniques. Electron microscopy can't be used on living tissue, and optical (light) microscopy can't penetrate very deeply into tissue because light scatters as it travels through tissue near the surface. Thus traditionally microscopic images of the living brain have only been made near the surface. Yet researchers would like to know more about certain deep-tissue areas of the brain, which are critical to understanding Alzheimer's and Parkinson's disease, for example.

Scientists often use some form of fluorescence microscopy to image tissue. In conventional "one-photon" fluorescence imaging, the scientist injects a dye into tissue and then shines a bright light. The tissue fluoresces, or radiates, light of a different colour in response. However, a problem with one-photon fluorescence is that the deep tissue causes the photons to ricochet, or scatter, as they return to the detector. The result is a background haze in the images, almost like viewing the sample through a cloud.

It's possible to get rid of background haze and reduce the scattering using two-photon fluorescence imaging. Instead of one higher-energy photon, researchers bombard the molecule with two photons of lower energy. Their combined energies total the energy required to excite the fluorescent-dye molecules used to mark the tissue. The technique gets rid of the background haze and reduces scattering, because molecules outside the area of interest are much less likely to absorb a pair of photons simultaneously and fluoresce in response.

While two-photon microscopy offers an alternative to traditional one-photon fluorescence microscopy, it still only penetrates brain tissue down to about 500-600 microns – barely scratching the surface.

To get at the deep structures, the Stanford researchers turned to microendoscopy, tiny, minimally invasive optical probes that could be inserted deep into living brain tissue.

To make one group of images, the researchers inserted the microendoscope into the hippocampus of a mouse, about a millimetre below the surface to obtain an image. The two-photon imaging provided an additional 80 microns of depth, below the hippocampal surface.

The mice were injected with a fluorescein dye – an FDA-approved contrast agent that is most commonly used for retinal exams in humans. The fluorescein labeled the blood plasma so the vessels in the brain could be clearly seen.

When combined with two-photon fluorescence, the result is a system that brings the power of a cutting-edge imaging technique to the deep tissues of the brain. By creating a handheld device based on some of the latest advances in micromotors, lensing and fibre optics, the researchers were able to establish a new technique that enables them to obtain microscopic images deeper in the living brain than was possible before microendoscopy.

There are many different options for further exploration, now that the technique has been successfully demonstrated, ranging from biomedical research to clinical imaging applications. The Stanford researchers will be looking into several of those options.
