The market for wearable electronics that continuously monitor biosignals is predicted to be worth approximately $572.06bn by 2033. However, many of the materials used for bioelectrodes, such as metals, conductive polymers, and hydrogels, often lack the flexibility to stretch the skin without breaking and have low humidity permeability, leading to sweat buildup and discomfort.
Addressing these limitations, a research team led by Assistant Professor Tatsuhiro Horii and Associate Professor Toshinori Fujie from Tokyo Institute of Technology (Tokyo Tech) has developed a bioelectrode material composed of layers of conductive fibrous networks consisting of single-wall carbon nanotubes (SWCNTs) on a stretchable poly(styrene-b-butadiene-b-styrene) (SBS) nanosheet. Their findings are detailed in NPG Asia Materials.
According to the team, the nanosheet conforms tightly to the skin, allowing for precise biosignal measurements, while the carbon nanotube fibres maintain the material’s stretchability and humidity permeability.
“Self-supporting electrodes that are stretchable, permeable to humidity, and conformable to skin surface bumps are required to allow for the natural deformation of skin without restricting body movements,” Horii said in a statement.
The researchers applied SWCNTs as aqueous dispersions onto SBS nanosheets, creating multiple layers reaching a thickness of 431nm.
Each coating of SWCNTs increased the density and thickness of the fibres, modifying the bioelectrode's characteristics.
While adding more SWCNT layers increased nanosheet stiffness (from an initial 48.5MPa elastic modulus to 60.8MPa for a single layer and 104.2MPa for five layers), the bioelectrode maintained favourable flexibility.
Pristine SBS nanosheets and those with one or three layers of SWCNTs (SWCNT 3rd-SBS) stretched elastically by 380 per cent of their original length before permanent deformation. This flexibility surpasses metal electrodes like gold, which have Young's moduli in the several-hundred-GPa range and can only stretch less than 30 per cent of their original length before breaking.
Another requirement for bioelectrodes is high water vapour permeability to prevent sweat buildup during exercise. Adding SWCNTs is beneficial as its fibrous network structure improves breathability compared to continuous films.
In experiments measuring water vapour transmission rate (WVTR), researchers found that SWCNT 3rd-SBS exhibited a WVTR of 28,316g m-2 (2 h)-1, which is twice that of normal skin.
To test the material’s durability, the researchers immersed the bioelectrodes in artificial sweat and subjected them to repeated bending, measuring the change in resistance.
In these tests, they found that the resistance increased negligibly, by only 1.1 times in sweat and by 1.3 times over 300 cycles of bending. Furthermore, the SWCNT 3rd-SBS nanosheets showed little to no detachment after being rubbed 10 times, indicating its suitability for prolonged use.
To assess its real-world performance, the researchers compared an SBS nanosheet with three layers of SWCNT to commercially available bioelectrode materials such as Ag/AgCl gel electrodes.
The bioelectrodes were attached to the forearm, and surface electromyography (sEMG) measurements were taken during gripping motions.
In this experiment, the performance of the SWCNT-SBS nanosheet was comparable to that of commercial Ag/AgCl gel electrodes, achieving similar signal-to-noise ratios of 24.6dB and 33.3dB, respectively.
“We obtained skin-conformable bioelectrodes with high water vapour permeabilities, which showed comparable performance in sEMG measurements to those of conventional electrodes,” said Fujie.
