Fishnet refraction

Researchers at the US Department of Energy’s Ames Laboratory have developed a material with a negative refractive index for visible light.

Ames Laboratory senior physicist Costas Soukoulis, working with colleagues in Karlsruhe, Germany, designed a silver-based, mesh-like material that is said to mark the latest advance in the rapidly evolving field of metamaterials, materials that could lead to a wide range of new applications as varied as ultrahigh-resolution imaging systems and cloaking devices.

The discovery, detailed in recent issues of Science, Optic Letters, and Nature, marks a significant step forward from existing metamaterials that operate in the microwave or far infrared – but still invisible –regions of the spectrum. Those materials, announced last summer, were heralded as the first step in creating an invisibility cloak.

Metamaterials, also known as left-handed materials, are artificially created materials that provide optical properties not found in natural materials. Natural materials refract light, or electromagnetic radiation, to the right of the incident beam at different angles and speeds. However, metamaterials make it possible to refract light to the left, or at a negative angle. This backward-bending characteristic provides scientists the ability to control light similar to the way they use semiconductors to control electricity, which opens a wide range of potential applications.

‘Left-handed materials may one day lead to the development of a type of flat superlens that operates in the visible spectrum,’ said Soukoulis, who is also an Iowa State University Distinguished Professor of Liberal Arts and Sciences. ‘Such a lens would offer superior resolution over conventional technology, capturing details much smaller than one wavelength of light to vastly improve imaging for materials or biomedical applications,’ such as giving researchers the power to see inside a human cell or diagnose disease in a baby still in the womb.

The challenge that Soukoulis and other scientists who work with metamaterials face is to fabricate them so that they refract light at ever-smaller wavelengths. The “fishnet” design developed by Soukoulis’ group and produced by researchers Stefan Linden and Martin Wegener at the University of Karlsruhe was made by etching an array of holes into layers of silver and magnesium fluoride on a glass substrate. The holes are roughly 100 nanometres wide. ’We have fabricated for the first time a negative-index metamaterial with a refractive index of -0.6 at the red end of the visible spectrum (wavelength 780 nm),’ said Soukoulis. ‘This is the smallest wavelength obtained so far.’

While the silver used in the fishnet material offers less resistance when subjected to electromagnetic radiation than the gold used in earlier materials, energy loss is still a major limiting factor. The difficulties in manufacturing materials at such a small scale also limit the attempts to harness light at smaller wavelengths.

‘Right now, the materials we can build at THz and optical wavelengths operate in only one direction,’ Soukoulis said, ‘but we’ve still come a long ways in the six years since negative-index materials were first demonstrated.’

‘However, for applications to come within reach, several goals need to be achieved,’ he added. ‘First, reduction of losses by using crystalline metals and/or by introducing optically amplifying materials; developing three-dimensional isotropic designs rather than planar structures; and finding ways of mass producing large-area structures.’
