Graphene has many favourable properties but the so-called wonder material is brittle, which has led to efforts to reinforce it with carbon nanotubes.
Now, researchers at Rice University in Texas have found that fracture-resistant "rebar graphene" - developed by the Rice lab of chemist James Tour in 2014 - is more than twice as tough as pristine graphene.
On the two-dimensional scale, graphene is stronger than steel, but because graphene is so thin, it is subject to ripping and tearing.
In a new study published in ACS Nano, Rice materials scientist Jun Lou, graduate student and lead author Emily Hacopian and collaborators, including Tour, stress-tested rebar graphene and found that nanotube rebar diverted and bridged cracks that would otherwise propagate in unreinforced graphene.
The experiments showed that nanotubes help graphene stay stretchy and also reduce the effects of cracks. That could be useful not only for flexible electronics but also electrically active wearables or other devices where stress tolerance, flexibility, transparency and mechanical stability are desired, Lou said.
Both the lab's mechanical tests and molecular dynamics simulations by collaborators at Brown University revealed the material's toughness.
Graphene's excellent conductivity makes it a strong candidate for devices, but its brittle nature is a downside, Lou said. His lab reported two years ago that graphene is only as strong as its weakest link. Those tests showed the strength of pristine graphene to be "substantially lower" than its reported intrinsic strength. In a later study, the lab found molybdenum diselenide, another two-dimensional material of interest to researchers, is also brittle.
Tour approached Lou and his group to carry out similar tests on rebar graphene, made by spin-coating single-walled nanotubes onto a copper substrate and growing graphene on top of them via chemical vapour deposition.
https://www.youtube.com/watch?v=Kiq9BKby3VM&feature=youtu.be
To stress-test rebar graphene, Hacopian, Yang and colleagues had to pull it to pieces and measure the force that was applied. Through trial and error, the lab developed a way to cut microscopic pieces of the material and mount it on a testbed for use with scanning electron and transmission electron microscopes.
"We couldn't use glue, so we had to understand the intermolecular forces between the material and our testing devices," Hacopian said. "With materials this fragile, it's really difficult."
Rebar didn't keep graphene from ultimate failure, but the nanotubes slowed the process by forcing cracks to zig and zag as they propagated. When the force was too weak to completely break the graphene, nanotubes effectively bridged cracks and in some cases preserved the material's conductivity.
In earlier tests, Lou's lab showed graphene has a native fracture toughness of 4 megapascals, whereas rebar graphene has an average toughness of 10.7 megapascals, he said.
Simulations by study co-author Huajian Gao and his team at Brown confirmed results from the physical experiments.
The rebar graphene results are claimed to be a first step toward the characterisation of many new materials. "We hope this opens a direction people can pursue to engineer 2D material features for applications," Lou said.
