’Many researchers – including our lab – have developed prototype sensors for wearable health systems, but there was a clear need to develop antennas that can be easily incorporated into those systems to transmit data from the sensors, so that patients can be monitored or diagnosed,’ said Dr. Yong Zhu, an associate professor of mechanical and aerospace engineering at NC State and senior author of a paper describing the work.
The researchers wanted to develop an elastic because wearable systems can be subject to a variety of stresses as patients move around.
According to NCSU, the researchers used a stencil to apply silver nanowires in a specific pattern and then poured a liquid polymer over the nanowires to create an appropriately resilient, effective antenna. When the polymer set, it formed an elastic composite material that has the nanowires embedded in the desired pattern.
This patterned material forms the radiating element of a microstrip patch antenna. By manipulating the shape and dimensions of the radiating element, the researchers can control the frequency at which the antenna sends and receives signals. The radiating layer is then bonded to a ground layer, which is made of the same composite, except it has a continuous layer of silver nanowires embedded.
The researchers also learned that, while the antenna’s frequency does change as it is stretched, the frequency stays within a defined bandwidth. As the frequency changes almost linearly with the strain, the antenna can be used a wireless strain sensor as well.
’Other researchers have developed stretchable sensors, using liquid metal, for example,’ Zhu said in a statement. ’Our technique is relatively simple, can be integrated directly into the sensors themselves, and would be fairly easy to scale up.’
The work on the new, stretchable antenna builds on previous research from Zhu’s lab to create elastic conductors and multifunctional sensors using silver nanowires.
The paper, Stretchable and Reversibly Deformable Radio Frequency Antennas Based on Silver Nanowires, is published online in ACS Applied Materials & Interfaces.
Lead author of the paper is Lingnan Song, an undergraduate at Zhejiang University who worked on the project at NC State during an exchange program. Co-authors include Amanda Myers, a Ph.D. student at NC State; and Dr. Jacob Adams, an assistant professor of electrical and computer engineering at NC State.
